high quality insulated panels cold storage for steel buildings

FOB Reference Price:Get Latest Price
US $9.5-16.4 / Square Meter | 200 Square Meter/Square Meters sandwich panels (Min. Order)
Supply Ability:
4000 Square Meter/Square Meters per Day sandwich panels
Port:
QingDao
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Henan, China (Mainland)
Brand Name:
CANGLONG GROUP
Model Number:
PU Sandwich Panel
Type:
Polyurethane Sandwich Panels
Product name:
high quality insulated panels for cold storage
Insulation material:
Polyurethane (PU)
Control system:
Full automatic control system
Application:
Medicine, seafood,fruits and vegetables ...
Voltage:
220V/380V
Panel thickness:
50,75, 100, 150,200mm
Dimension(L*W*H):
Customized Size
Compressive strength:
>0.2Mpa
Self-extinguishing time:
7s
Packaging & Delivery
Packaging Details
Plastic film on surface sea worthy packing,or as customer's require.shipped by container
Delivery Time
10-15 DAYS
high quality insulated panels cold storage for steel buildings
Product Description
 Product  Imformation

PU cold storage room panel is a kind of board used for enclosing structures, which has good heat insulationand higher intensity.It can reduce the heat transmission caused by difference in the internal and external temperature, and get to maximum efficiency of freezing and refrigeration systems. Designed scientifically and easy to use. It is a new type of heat insulation material for lower construction cost.Panels are in multiple varieties and specifications to meet the need of various sites and projects.

Type
Polyurethane(pu)Sandwich Panels
Panel Material
Painted steel sheet,stainless steel sheet,or other.
Place of Origin
China
Density
40-42kg/m3
Length
Customize
Effective Width
1000mm
Core thickness
50mm,75mm,100mm,150mm,200mm
Features
soundproof, fireproof, waterproof
Certificates
CE, ISO14001, ISO9001,
Color
White, Grey, Sliver, Sea Blue, Red, etc. as required
Lifetime
20-30 years
Fire proof rate
B1
Usage
Vatious roofs and walls referring to the large size factory Building,storages,exhibition halls,gymnasiums,etc.

Cold room panel, size, and temperature:

Thickness
Suitable temperature
50
5°C or above
75
-5°C or above
100
-28°C or above
150
-35°C or above
200
-45°C or above

Specifications

1)keep fruits, vegetables and eggs fresh.
2)Bitzer compressors.
3)PU foam sandwich panels.
4)Swing or Sliding door

Product pictures

Related Parts

Product Application

Food(meat, vegetable,fruit,dairy,drink),medicine,chemical,electronics,etc.
-- Materials: polyurethane and metal sheet. Metal sheet: it is can be with painted steel sheet and
stainless steel sheet for choice.
-- With electric heating wire around doorframe to void icing.
-- Safe doorknob inside.
-- Positive plastic seal fixed to door to avoid cooling air losses.
-- We can do customized dimension according to customers'requirements.
We have access to all the leading Cold Room refrigerators brands and can offer independent advice,









Cold Storage Room For Cheese

The storage temperature kept at 0℃,the cold panel thickness is 75mm.







Cold Storage Room For Vegetable

The storage temperature kept at 0℃,the cold panel thickness is 75mm.









Cold Storage Room For Fruit

The storage temperature kept at 0℃,the cold panel thickness is 75mm.









Cold Storage Room For Dairy

The storage temperature kept at -5℃,the cold panel thickness is 75mm.







Cold Storage Room ForMedicine

The storage temperature kept at -5℃,the cold panel thickness is 75mm.









Cold Storage Room For Beverage

The storage temperature kept at -5℃,the cold panel thickness is 75mm.









Cold Storage Room For Fish

The storage temperature kept at -28℃,the cold panel thickness is 100mm.







Cold Storage Room For Meat

The storage temperature kept at -28℃,the cold panel thickness is 100mm.

Packing & Shipping

Packing and shipping:
1. Standard wooden case.
2. Completely ice machine contain: ice machine, cooling tower, water pump, water pipes and water pipe fittings.
3. Machine come into use, customer only need prepare power for the machine.
4. All required components for install the machine will be provided.
